Biggest pile driver with 110kw

Our electric handheld pile drivers come in two models: the single-motor SC5500S, boasting a power of 5500W, and the dual-motor SC11000D, with an impressive power of 11000W. Both torque is 5500-10500nm. These are arguably the most powerful handheld electric pile drivers available on the market.

Below is FAQ for them:

1, What’s the RATED current and power?

A: Both two types has high-speed motors, and no rated current and power, the power and current increase with the increase of load. At the beginning of operating, the no-load will reach 3000W, and the deeper the ground is, the greater the current will be.

2, What’s current need?

A: SC5500S need current less than 32A, but SC11000D needs a current of more than 32A, similar to our home has a power switch, there will be overload protection, basically to 42A, there will be power outage protection.

3, What’s the voltage need?

A: Both two pile drivers need a voltage of 220v, and if your voltage is 120V, it needs a transformer to raise the voltage from 120V to 220V.

4, Will this product run on 30 amp double pole breaker ?

A: it's better 63a. There will be risk of trip by 30a.

5, What gauge extension cord to use to operate this machine in USA?

11AWG wire gauge is suitable(length not exceed 50m),and 10 AWG wire gauge should be choosed if length more than 50m.

6, should there be 2 wire or 3 wire in the cable?

A: 3 wire .

7.What’s the max torque?

A: Both two pile drivers have 6000-10500nm torque. When the motor is working, the motor speed will drop a little when it encounters hard soil. As the speed drops, the torque continues to increase.

8, How do I choose the suitable model?

A: Two factors are the main key. 1, the pile length and diameter to be driving. 2, the situation of your earth, SC11000D equipped with two motors which has more power, when If you encounter the situation of carrying stones when driving piles, you need more power .

9. Does it have lever to press to go slower or faster?

A: NO. The more complicated it is, the easier it is to break.

10, Does it have reverse to take the ground screw out of the ground?

A: Yes, Positive and negative rotation is available.

11, Does your pile disc flange can be suitable with my piles?

A: Yes, our pile disc flange contains the link dimensions that cover most of the piles, if your pile is special, you can make the hole on the disc directly.

12, What’ the material of the support stick and handrail?

A: The support stick is aluminum alloy, handrail is stainless steel.
