Excavator Tilt Bucket

Name: Excavator Tilt Bucket
Brand: YANTAI SC EQUIPMENT CO.,LTD.

Tilting bucket widely used in clean up, ditching or grading applications. With 45 degree tilt angle in each directions, tilting bucket give you the versatility to work with leveling and grading without removing the excavator which increase more flexibility and productivity. We offer a range of dual cylinder tilting buckets for excavators from 1 – 30 ton. SC Equipment manufacturer excavator bucket attachments with custom solutions and competitive prices.

Inquiry

Features Specification Images Video

Features of Excavator Tilt Bucket

Tilting 45° left and right to reach any slopes.
Equipped with bolt-on cutting edge and side cutters for better protection.
Available in various widths and sizes to satisfy your works.
Two hydraulic cylinders with hardened rods for excellent holding power.
Custom cutting edge, logos and other features are available as request.

Specification of Excavator Tilt Bucket

excavator weight/tons	Model	Width/mm	Capacity m³	Weight/kg
1-4	SC04-900	900	0.14	110
	SC04-1000	1000	0.16	160
	SC04-1200	1200	0.18	176
	SC04-1350	1350	0.2	187
	SC04-1500	1500	0.22	200
4-6	SC06-1200	1200	0.22	220
	SC06-1350	1350	0.25	260
	SC06-1500	1500	0.28	280
6-11	SC11-1200	1200	0.28	380
	SC11-1500	1500	0.36	430
	SC11-1700	1700	0.48	450
	SC11-1800	1800	0.44	480
11-14	SC14-1500	1500	0.48	790
	SC14-1800	1800	0.57	660
	SC14-2000	2000	0.64	850
14-18	SC18-1500	1500	0.63	700
14-18	SC18-1800	1800	0.57	820
